Part Junxing H20 STR Cam / Module

Part Junxing H20 STR Cam / Module

$99.00
$99.00
Sale Sold out
Taxes included. Shipping calculated at checkout.
Junxing H20 STR Cam & Module Configuration
Cam and Module Compatibility:
  • Small Base Cam AB: Fits Module A and Module B.
    • Module A Draw Length Range: 24.5" – 26.5"
    • Module B Draw Length Range: 27" – 28"
  • Large Base Cam CD: Fits Module C and Module D.
    • Module C Draw Length Range: 28.5" – 29.5"
    • Module D Draw Length Range: 30" – 31"
String and Cable Requirements:
The string and cables for the AB base cam and the CD base cam are different lengths:
  • AB Cam Setup: String Length: 55-3/4" | Cable Length: 39-7/8"
  • CD Cam Setup: String Length: 58.3/8" | Cable Length: 40-1/4"
Draw Length Conversions:
If you want to change your draw length from an AB cam size to a CD cam size (or vice versa), you will need three main components for the conversion to happen:
  1. The new base cam
  2. The matching module
  3. A new set of strings and cables
